| Frame | Aluminum Frame, 150mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™ |
| Fork | DVO Diamond 36 Core, High/Low Speed Compression | Rebound , 160mm, 44mm Offset |
| Rear Shock | DVO Topaz Core, 205x60mm TR |
| Rear Shifter | Shimano CUES SL-U6000-11R, 11sp |
| Rear Derailleur | Shimano CUES RD-U6000, 11sp, GS |
| Crankset | Prowheel Aluminum Bosch Cranks, 34T, 155mm (S1,S2,S3) - 160mm (S4, S5) |
| Bottom Bracket | Bosch PX |
| Cassette | Shimano CUES CS-LG3400-11, 11-50T, 11sp |
| Chain | Shimano CUES CN-LG500-Q, 11sp |
| Front Brake | TRP Slate EVO, Organic Pads |
| Front Brake Rotor | TRP 203mm, 2.3mm Thickness, Centerlock |
| Rear Brake | TRP Slate EVO, Organic Pads |
| Rear Brake Rotor | TRP RS01E, 180mm, 2.3mm Thickness, Centerlock |
| Brake Levers | TRP Slate EVO |
| Handlebar | Norco 6061 DB Alloy, 800mm, 25mm rise (S1,S2) - 35mm rise (S3,S4,S5) |
| Stem | Norco 6061, 40mm Length, 35mm Clamp |
| Seatpost | TranzX YSI34QL , 31.6mm, 125 (S1) -150mm (S2) -170mm (S3) -200mm (S4,S5) |
| Headset | FSA No.55 Sealed Bearing, 1 1/8" - 1.8" Tapered, ( ZS44/28.6 | ZS56/40 ) |
| Saddle | WTB Solano Med, 142x240 mm, Steel Rails |
| Grips | WTB Wavelength, 140mm Length |
| Front Hub | Shimano HB-MTC500-15-B,15x110mm Boost, 32H, C-lock |
| Rear Hub | Shimano FH-TC500-MS-B, 12x148mm Boost, HG, 32H, C-Lock |
| Rims | WTB ST Tough TCS 2.0 ,30 mm, 32H, 29"-27.5" F/R |
| Front Tire | Maxxis Assegai, 3C MaxxGrip EXO+, 29x2.5", Folding |
| Rear Tire | Maxxis Minion DHR II, 3C Maxx Grip DD, 27.5.5x2.4", Folding |
| Spokes/Nipples | Sapim Sprint DB Spokes 2.0/1.8/2.0,Black stainless steel |
| Drive Unit | Bosch Performance Line PX, 90 Nm / 700W |
| Battery | Bosch PowerTube 600 Wh |
