| Frame | Alpha Gold Aluminum, DuoTrap S compatible, internal cable routing, flat mount disc, rack & fender mounts, 135x5mm QR |
|---|---|
| Fork | FX Steel, flat mount disc, rack mounts, 405mm axle-to-crown, ThruSkew 5mm QR |
| Hub front | Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
|---|---|
| Skewer front | 130x5mm QR, ThruSkew |
| Hub rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR |
| Skewer rear | 152x5mm QR |
| Rim | Bontrager Connection, alloy, double-wall, 32-hole, Schrader valve |
| Tire | Bontrager H2 Comp, wire bead, 30 tpi, 700x35mm |
| Max tire size | 700x38mm without fenders, 700x35mm with fenders |
| *Shifter | Size: XS, S, M, L, XL, XXL Shimano EF500, 2 speed |
|---|---|
| Size: XS, S, M, L, XL, XXL Shimano EF500, 8 speed |
|
| Front derailleur | Shimano Tourney TY710, 34.9 mm clamp, top swing, dual pull |
| Rear derailleur | Shimano Altus M310 |
| Crank | Forged alloy, 46/30, chainguard, 170 mm length |
| Bottom bracket | Sealed cartridge, 68mm |
| Cassette | Shimano HG31, 11-32, 8 speed |
| Chain | KMC Z8.3 |
| Pedal | Wellgo nylon platform |
| Max chainring size | 1x: 42T, 2x/3x: 48T |
| Saddle | Bontrager Sport |
|---|---|
| Seatpost | Bontrager alloy, 27.2mm, 12mm offset, 330mm length |
| *Handlebar | Size: XS, S, M, L Bontrager Riser, steel, 25.4mm, 30mm rise, 600mm width |
| Size: XL, XXL Bontrager Riser, steel, 25.4mm, 30mm rise, 620mm width |
|
| Grips | Bontrager Satellite |
| *Stem | Size: XS, S, M Bontrager alloy, 25.4 mm clamp, 10-degree, 90 mm length |
| Size: L, XL, XXL Bontrager alloy, 25.4 mm clamp, 10-degree, 110 mm length |
|
| Headset | 1 1/8" steel threadless |
| Brake | Tektro MD-U310 mechanical disc, flat mount, 160mm rotor |
| Rotor size | Max brake rotor sizes: 160mm front & rear |
| Weight | M - 12.68 kg / 27.96 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
