Frame | Double Butted Alloy E-Bike Frame, Internal Cables |
Fork | Alloy, Steel Steerer |
Rear Shifter | Shimano Alivio SL-M4000 |
Rear Derailleur | Shimano Alivio RD-M4000 |
Crankset | Shimano FC-E6100, 38T, 170mm |
Cassette | Shimano Alivio CS-HG400, 11-36T, 9 Speed |
Chain | KMC E9-Sport |
Front Brake | Tektro HD-M275, Hydraulic Disc, E-Rated, Resin Pads |
Front Brake Rotor | Tektro 160mm |
Rear Brake | Tektro HD-M275, Hydraulic Disc, E-Rated, Resin Pads |
Rear Brake Rotor | Tektro 160mm |
Brake Levers | Tektro HD-M285 Hydraulic |
Handlebar | Custom Alloy 660mm, 60mm Rise |
Stem | Alloy 70mm (S, M), 80mm (L), 31.8mm Clamp |
Seatpost | JD TranzX Dropper, 31.6mm, 80mm (S, M), 100mm (L) |
Headset | Zero Stack |
Saddle | Norco Comfort, Elastomers |
Grips | Dual Density Ergonomic, Single Lock |
Pedals | City Pedal, Kraton Traction Inlay |
Front Hub | Sealed Bearing, 15x100mm, 6-bolt |
Rear Hub | Sealed Bearing, 12x142mm, HG, 6 Bolt |
Rims | Alloy DW Disc, 27.5" |
Front Tire | Kenda Kwick Seven5, 2.2", 60 TPI, Gumwall |
Rear Tire | Kenda Kwick Seven5, 2.2", 60 TPI, Gumwall |
Spokes/Nipples | Stainless Black |
Drive Unit | Shimano STEPS E6100 |
Battery | Shimano E8010 504Wh |
Switch | Shimano E7000 |
Display | Shimano E7000 |
